A robust powerful and enduring pre-shredder!

TYRON, the sturdy twin-shaft primary shredder impresses with its powerful performance of up to 770 hp and its aggressive material infeed. Our Viking, thanks to the intelligent HAAS twin-shaft technology, is the ideal solution for effectively shredding even the most difficult materials. Its two shredding shafts are independently driven. This seemingly trivial feature has many advantages.

With this shredder, you can adjust the shaft speed, direction of rotation and reversing times at any time depending on the material. Wrapping of wires and long-fibre materials is avoided, throughput is maximised! Compared to a synchronously running shredder, the HAAS TYRON reduces wear and downtimes. The solid construction ensures a high economic efficiency and long service life – the oldest TYRON still in operation today has already achieved more than 35,000 operating hours!

You will receive your TYRON with an optimally matched tool configuration. Depending on your requirements and wishes, you will receive a suitably equipped breaking unit – as standard, the shredding tools are hard-faced ex works!

Range of application

  • MSW - Municipal Solid Waste
  • Waste Wood
  • Pallets
  • C&D - Construction & Demolition Recycling
  • Railway Sleepers
  • Residual Waste
  • Domestic Waste
  • Industrial Waste
  • Bulky Waste
  • Cable Drums
  • Paper Rolls
  • Green Waste
  • Mattresses
  • Roots
  • Aluminium
  • Organic Waste
  • PVC-Profiles / plastic window frame

Product advantages

  • Can be used at any location (comfortable transport measurements)
  • Easy and quick positioning thanks to crawler track and radio remote control
  • Shreds different materials with just one tool configuration
  • High throughput capacity of up to 100 t/h
  • Resistant against foreign bodies
  • Low wear costs and long lifetime
  • Service- und maintenance-friendly
  • No wrappings – self-cleaning
  • Quiet main drive

Applications

Enormous throughput of up to 100 t/h

The TYRON impresses with its exceptional shredding technology. Thanks to the impurity-resistant construction, the primary shredder is suitable even for materials that are difficult to shred, e.g. railway sleepers with solid iron plates or difficult commercial waste. The end product can vary from 150 mm to 500 mm depending on the tool configuration. The twin-shaft shredder is boasts impressive performance across various applications, such as the processing of refuse-derived fuels (RDF), the pre-shredding of waste wood, the mechanical-biological treatment of residual waste and many other applications.
High-quality tool configurations, bespoke to the feed material reliably produce high quality end product. The aim is to return valuable raw materials to the recycling loop.

End product from “fine” ca. < 150 mm to “coarse” ca. < 500 mm, depending on tool configuration (individual solutions on demand)

  • MSW - Municipal Solid WasteMSW - Municipal Solid Waste
  • Waste WoodWaste Wood
  • PalletsPallets
  • C&D - Construction & Demolition RecyclingC&D - Construction & Demolition Recycling
  • Railway SleepersRailway Sleepers
  • Residual WasteResidual Waste
  • Domestic WasteDomestic Waste
  • Industrial WasteIndustrial Waste
  • Bulky WasteBulky Waste
  • Cable DrumsCable Drums
  • Paper RollsPaper Rolls
  • Green WasteGreen Waste
  • MattressesMattresses
  • RootsRoots
  • AluminiumAluminium
  • Organic WasteOrganic Waste
  • PVC-Profiles / plastic window framePVC-Profiles / plastic window frame

Model overview TYRON mobile with diesel-motor

  • TYRON 1500257 kW
  • TYRON 1500 XL294 kW
  • TYRON 2000257 kW
  • TYRON 2000 XL297 kW
  • TYRON 2500 566 kW

Notification:
Optional: the XL-Version is available for the models 1500 and 2000, this includes:
A stronger hydraulic system and 30 % more power!

Serial Equipment-Highlights

  • Traffic-light system for the visual identification of the operating state
  • Easy access to the shredder shafts and easy exchange of the breaker bar due to the foldable transfer chute
  • Spacious and service-friendly engine compartment
  • Pivoting cooler with Cleanfix-System®
  • Pre-hardfaced shafts and tools to reduce wear

Options

  • strengthened Neodym Magnet
  • hydr. height adjustable Magnet
  • Tracks with rubber shoes
  • Trailer
  • Hook lift frame hydr. lifting axle
  • Outfeed belt extension
  • Hopper extension
  • Fine Tools
  • Hardfaceing
  • Special varnishing
  • Online Monitoring



    • Belt with steel inlay
    • Belts oil- and fat-resistant
    • Conveyor speed adjustable
    • Drive drum stainless steel (for magnetic insert)
    • Engine Tier 2 without SCR
    • CAT engine on demand
    • Heater for hydraulic oil tank
    • Fire extinguishing system (engine room)
    • Dust suppression system



Technical Data

The right model for every requirement – our popular TYRON shredder is available in 3 basic versions: 1500, 2000 and 2500. The individual models are differentiated by the dimensions of the shredding shafts, the drive power and the machine dimensions. With an XL-Power upgrade, you also get more power and, thanks to the dynamically reinforced hydraulic system, a significantly higher throughput. We will be more than pleased to send you further technical specifications on request.



  • 1500
  • 1500 XL
  • 2000
  • 2000 XL
  • 2500
  • Diesel engine350 PS / 257 kW
  • Number of shafts2 *
  • shredding chamber ø x Length (mm): 700 x 1.500
  • rpmmax. 40 **
  • weight18-30 t
  • Diesel engine400 PS / 294 kW
  • Number of shafts2 *
  • shredding chamber ø x Length (mm): 700 x 1.500
  • rpmmax. 40 **
  • weight18-30 t
  • Diesel engine350 PS / 257 kW
  • Number of shafts2 *
  • shredding chamber ø x Length (mm): 700 x 2.000
  • rpmmax. 40 **
  • weight18-30 t
  • Diesel engine400 PS / 294 kW
  • Number of shafts2 *
  • shredding chamber ø x Length (mm): 700 x 2.000
  • rpmmax. 40 **
  • weight18-30 t
  • Diesel engine770 PS / 566 kW
  • Number of shafts2 *
  • shredding chamber ø x Length (mm): 900 x 2.500
  • rpmmax. 30 **
  • weight30-45 t

* The number and form of the tools is adjusted according to the requested end product.

** The revolutions per minute of the shafts lies between 0-40 rpm and can be infinitely adjustable. Furthermore, both shafts are driven separately and can therefore be driven with different speed. Due to the variety of the discs per shaft and the tools per disc, an end product of around 150 – 500 mm is can be achieved.

Pictures

You can use our mobile TYRON flexibly at different locations thanks to its crawler track. You can choose between different materials for shredding. We show you some photos and video impressions here. On request, we will be happy to provide you with further image and video material to suit your requirements – please don’t hesitate to contact us.

Videos

Downloads

Our brochures will provide you with some initial information on our TYRON primary shredder. This cannot replace comprehensive advice. Please tell us what your requirements are. What material would you like to recycle? What end product do you need and what are your on-site requirements? We would be happy to create an individual machine configuration for you and provide you with additional information if required. Please feel free to call us at +49 2661 9865-0.
